| Part Number: | SC-Flare3US |
| Uplink Frequency Range (MHz): | 698-716 / 776-787 / 824-849 / 1850-1915 / 1710-1755 (G Block Included) |
| Downlink Frequency Range (MHz): | 728-746 / 746-757 / 869-894 / 1930-1995 / 2110-2155 (G Block Included) |
| Donor/Server Port Impedance: | 75 Ohm / 50 Ohm |
| Maximum Gain: | 72 dB |
| Noise Figure: | 7 dB |
| VSWR: | ≤2.0 |
| Supported Standards: | CDMA, WCDMA, GSM, EDGE, HSPA+, EVDO 4G LTE and all cellular standards |
| AC Input: | Input: AC 110 – 240 V, 60 Hz ; Output: DC 5V / 3A |
| Maximum Output Power: | 1 Watt EIRP |
| Cable: | RG-6 (50 ft) |
| RF Connector: | F-Female |
| Power Consumption: | <12W |
| Weight: | 1.81 lb |
| Dimensions: | 5.125″ × 7.25″ × 5.625″ |
| Weight | 1.81 lbs |
|---|---|
| Dimensions | 5.125 × 7.25 × 5.625 in |
