Data Sheet
Fusion5X_2.0_User_Guide
| Uplink Frequency Range (MHz): | 698-716 / 776-787 / 824-849 / 1850-1915 / 1710-1755 (G Block Included) |
| Downlink Frequency Range (MHz): | 728-746 / 746-757 / 869-894 / 1930-1995 / 2110-2155 (G Block Included) |
| Supported Standards: | CDMA, WCDMA, GSM, EDGE, HSPA+, EVDO, LTE and all cellular standards |
| Input/Output Impedance: | 50 Ohm |
| Maximum Gain: | 72 dB |
| Noise Figure: | 8 dB |
| VSWR: | ≤2.0 |
| AC Input: | Input AC 110 V, 60 Hz / Output DC 12 V |
| Maximum Output Power: | 1 Watt EIRP |
| Downlink Power: | +16 dBm |
| Cable: | SC-400 |
| RF Connectors: | N-Female (both ends) |
| Power Consumption: | <25W |
| Operating Temperature: | -4ºF to +158ºF |
| Dimensions: | 9.25″ x 6.375″ x 1.375″ |
| Weight: | 4 lb 4 oz |
| Weight | 4.4 lbs |
|---|---|
| Dimensions | 9.25 × 6.375 × 1.375 in |
